Circular Cutting Knives

Score Cutter Blades Pipe Cutting Machine Knives Circular Cutting Knives

Henglida circular cutting knives include machine knives for plastic cutting machines, rubber cutting machines, rubber slicing machines and pipe cutting machines, etc.
1. Circular cutting knives for plastic industry include different kinds of circular knives like hobbing cutters used for pulverizing, slitter knives for slitting plastic products, etc.

2. Circular cutting knives for rubber industry also include slitter knives. (For more detailed information, please refer to CONTACT page and contact us directly.)

Technical data for rubber cutting machine knives:

Specifications	Outer diameter/Ф	Inner diameter/Ф	Teeth number
Ф100×Ф20×1	100	20	51
Ф100×25.4Ф×1	100	25.4	36
Ф110×Ф60×1	110	60	36
Ф100×Ф19×1	100	19	72

3. Pipe cutting machine knives
Pipe cutting machine knives are primarily used in pipe production lines. They move synchronously with pipes and at the same time revolve around the pipes. And finally, cutting blades will gradually cut off pipes into sections.
Pipe cutting machine knives made of different materials are provided. Welcome to contact us for more detailed information.

Technical data of pipe cutting machine knives:

Specifications	Outer diameter/Ф	Inner diameter /Ф	Thickness/B	Cutting edge angel/α
Ф100×Ф30×5	100	30	5	45o
Ф140×Ф40×5	140	40	5	45o
Ф140×Ф30×5	140	30	5	60o
Ф150×Ф35×3	140	30	3	60o
Ф150×Ф35×3	150	35	3	45o
Ф150×Ф36×3	150	36	3	45o
Ф160×Ф38×3	160	38	3	45o

Specifications	Outer diameter/Ф	Inner diameter/Ф1	Thickness/B	Cutting edge angel/α	Virtual circle diameter/Ф2	Diameter of hole 3-Ф3
Ф90×Ф25×3	90	25	3	60o	40	8
Ф155×Ф35×3.5	155	35	3.5	60o	50	8.5

Specifications	Outer diameter/Ф	Inner diameter/Ф1	Thickness/B	Pitch diameter/Ф2	Teeth width/C	Teeth depth/H
Ф88×Ф56×2	88	56	2	75	-	-
Ф200×Ф45×3	200	45	3	150	8.5	4.9
Ф250×Ф95×2.5	250	95	2.5	220	-	-

Specifications	Outer diameter/Ф	Inner diameter/Ф1	Thickness/B	Pitch diameter/Ф2	Virtual circle diameter/Ф3	Diameter of hole 4-Ф4
Ф90×Ф55×2	90	55	2	75	-	-
Ф170×Ф58×1.6	170	58	1.6	145	83	11
Ф200×Ф75×3	200	75	3	150	105	9

Specifications	Outer diameter/Ф	Inner diameter/Ф1	Thickness/B	Cutting edge angel/α	Teeth width/C	Teeth depth/H
Ф100×Ф55×2.5	100	55	2.5	45o	14	59.5
Ф100×Ф60×4	100	60	4	30o	5	62

Specifications	Outer diameter/Ф	Inner diameter/Ф1	Thickness/B	Cutting edge angel/α	Virtual circle diameter/Ф2	Diameter of hole 4-Ф4
Ф180×Ф100×6.5	180	100	6.5	45o	130	11
Ф200×Ф75×3	200	75	3	80o	105	9
